ASME SA269 TP304 1.4301奥氏体无缝光亮退火管
优势：
ASME SA269 TP304光亮退火管在没有氯化物和氟化物的腐蚀性溶液中表现良好。它们还具有优异的成形和焊接特性，并在腐蚀性环境中表现出良好的性能。无缝管还可以承受更高的压力。
ASME SA269 TP304是一种奥氏体级钢，包括标准无缝和焊接配置。ASME SA269 TP304卡套管采用镍和铬与其他构成合金的优异成分设计，增强了这些卡套管对腐蚀和氧化介质的抵抗力。
ASME SA269 TP304不锈钢卡套管的密度为8g/cm³，熔点为1400摄氏度。这些卡套管具有优异的机械性能，可以在不同的压力和温度下工作。
化学成分
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| TP304 | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
Tolerance Of ASTM A269 TP304 Tube
Size Inches | Tolerances, Inches | |||
OD, Inches | Wall | Ovality 2 x Tol., In. | Cut Length (b), In. | |
Less than 1/2 | ±0.005 | ±15% | —— | +1/8 –0 |
Over 1/2 to 1-1/2 | ±0.005 | ±10% | –0.065 | |
Over 1-1/2 to 3-1/2 | ±0.010 | ±10% | –0.095 | +3/16 –0 |
Over 3-1/2 to 5-1/2 | ±0.015 | ±10% | –0.150 | |
Over 5-1/2 to 8 | ±0.030 | ±10% | —— | |
TP304 Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| TP304 | 515 | 205 | 40 | 92 | 201 |
Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
|---|---|---|---|---|---|---|---|---|---|
0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 304/L/H | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
Equivalent Material For 304 Grade Stainless Steel
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 |
